Home/Laptops/Dell Precision 5690
Dell Precision 5690
Dell Laptop

Dell Precision 5690

CPUIntel Core Ultra 5 135H
GPURTX 1000 Mobile (Ada) 6GB
Display16 inches
Resolution1920 x 1200 pixels
RAM2x8 GB
Weight2.17 kg (4.78 lbs)
⇄ Compare with…
Powered by

Intel Core Ultra 5 135H

Perf.: 47 · iGPU: 85
53

Benchmarks

Geekbench 6 (Single-Core)2247
Geekbench 6 (Multi-Core)10,715
Cinebench 2024 (Single-Core)100
Cinebench 2024 (Multi-Core)813

Full specifications

Config

CPU
Intel Core Ultra 5 135H
GPU
RTX 1000 Mobile (Ada) 6GB

Case

Weight
2.17 kg (4.78 lbs)
Dimensions
353.68 x 240.33 x 20.5-22.17 mm / 13.92 x 9.46 x 0.81-0.87 inches
Area
850 cm2 (131.7 inches2)
Screen-to-body ratio
~87.3%
Side bezels
4.5 mm
Colors
Black
Material
Aluminum
Transformer
No
Opening angle
180°
Cooling system
Active
Vapor chamber
No
Liquid metal
No
Number of fans
2
Noise level (max. load)
51.9 dB

Display

Size
16 inches
Type
IPS LCD
Refresh rate
60 Hz
PPI
142 ppi
Aspect ratio
16:10
Resolution
1920 x 1200 pixels
HDR support
No
Sync technology
No
Touchscreen
No
Coating
Matte
Ambient light sensor
Yes
Contrast
1300:1
DCI-P3 color gamut
100%
Response time
30 ms

Battery

Voltage
11.55 V
Battery type
Li-Ion
Replaceable
No
Fast charging
Yes
Charging via USB (Power Delivery)
Yes
Charging port position
Left, Right
Charge power
100 / 165 W
Cable length
1 meters
Weight of AC adapter
479 grams

CPU

Base frequency
1.7 GHz
Turbo frequency
4.6 GHz
Cores
14 (4P + 10E)
Threads
18
L3 Cache
18 MB
Integrated GPU
Arc Graphics (8-Cores)
Fabrication process
7 nm

Graphics Card

TGP
50 W
Nvidia Optimus
Yes
Type
Dedicated
Fabrication process
5 nm
FLOPS
7.4 TFLOPS
Memory size
6 GB
Memory type
GDDR6
Memory bus
96 bit
Memory speed
~16 Gbps
Shading units (cores)
2560
Texture mapping units (TMUs)
80
Raster operations pipelines (ROPs)
48
GPU performance
7.4 TFLOPS
Blender GPU
1632

RAM

Channels
2x8 GB
Clock
7467 MHz
Type
LPDDR5X
Upgradable
No

Storage

Bus
PCI-E Gen 4.0 (4x)
Storage type
SSD (M2)
Channels
1x256 GB
Upgradable
Yes
Total slots
2
NVMe
Yes

Sound

Audio chip
Waves MaxxAudio 13
Speakers
2.2 (2 tweeters and 2 woofers)
Power
4x2W
Dolby Atmos
No
Loudness
~86.1 dB
Microphones
2

Connectivity

Wi-Fi standard
v7
Bluetooth
v5.4
Fingerprint
Yes
Infrared sensor
Yes
Optical drive
No
Webcam
Above the display
Webcam resolution
1920 x 1080
USB-A
No
USB Type-C
3x USB 4.0
Thunderbolt
Thunderbolt 4
HDMI
1x HDMI 2.1
DisplayPort
No
VGA
No
Audio jack (3.5 mm)
Yes
Ethernet (RJ45)
No
SD card reader
Yes
Proprietary charging port
No

Input

Keyboard type
Island
Numpad
No
Backlight
Yes
Key travel
1.9 mm
Size
13.6 x 8.5 cm
Surface
Glass
Windows Precision
Yes

Specifications compiled from NanoReview. Last updated 2026-09-27.
